100 Ton Press Brake

This machine has high labor productivity and high working precision for bending metal sheet, and adopts different shapes of upper and lower mould Can be bent into various shapes artifacts, stroke at a time can be to a bending forming of sheet metal, after a lot of bending can obtain more complex in the shape of the workpiece when equipped with the corresponding equipment, can also make a punch.


Different choices of 100ton press brake:
100ton/2500mm press brake bending machine
100ton/3200mm hydraulic bending machine
100ton/3100mm hydraulic bending machine
100ton/4000mm hydraulic bending machine
100ton/6000mm plate bending machine





100 Ton Hydraulic Press Brake Specification
Type

100T/2500
100T/3200
100T/4000
Nominal Force
KN
1000
1000
1000
Worktable Length
mm
2500
3200
4000
Poles Distance
mm
2020
2600
3000
Throat Depth
mm
320
320
320
Slider Travel
mm
150
150
150
Max Open
mm
350
400
400
Power
KW
11
11
11
Weight
kg
6000
6800
8400
Dimension
mm
2500×1600×2400
3200×1600×2600
4000×1600×2700

Here at GLDMA, there are different worktable processing length for 100 ton hydraulic press brake machine: 3200mm, 2500mm, 4000mm, and 6000mm and also can be customized according to actual usage.

The materials which can be processed by this series of 100 ton hydraulic press brakes are: Alloy sheet, Steel sheet, Carbon Alloy, Iron Plate, Galvanized sheet metal, and Stainless steel. Etc..

100 tons of bending machines can be divided into twisted and electro-hydraulic solutions, and the electro-hydraulic bending machine can be extended to 3-12 axes by combining different systems, making the machine have more functions and higher precision.

100 Ton Hydraulic Press Brake Price List
Please be noted that all the prices listed are for Shanghai FOB, and please feel free to contact us with the latest quotation. We accept TT/LC for payment. Here as below are some hot sale products prices for your reference, where the prices differ based on different requirements for functions and precision from different customers. Thus there are different control and operation systems for choice accordingly, for torsional bending machine, the systems include ESTUN E21, ESUTN E200P, DELEM DA41S; and for elctro-hydraulic press brake, DELEM da52s, DELEM da56s, DELEM da58t, DELEM da66t, etc.. You can choose different control systems for your press brake machine.

1. High quality 100 Ton *3200mm hydraulic cnc sheet metal press brake 100 tons pressure price
USD $8630 - 26,800 / Set

2. 100 ton * 2500mm Hydraulic Press Brake, Automatic 5mm CNC Plate Bending Machine price
USD $5,000 - 18,000 / Set

3. 100 Ton * 4000 m automatic cnc press brake machine price
USD $4,330 - 10,800 / Set

China new innovative automatic hydraulic bending machine
USD $27,200 - 62,000 / Set


Please do feel free to Email us or call us to 86 18055583445 at any time, we are glad to help you with the sheet metal processing.

Systems for Choice: http://www.gldma.com/controller/press-brake/

GLDMA New Design 100 Ton - 3200mm Press Brake
Press brakes are used to bend and fold metal by pressing it into a die. There are several types of press brakes. Examples include a hydraulic press brake, folding equipment, bending machine, press brake tooling, CNC brake press, and a sheet metal press brake. A hydraulic press brake is designed for both specialized sheet metal work and continuous production applications. A hydraulic press brake is designed to handle tough industrial production jobs from single-cycle operations to automated cell components. Folding equipment can be used to stiffen new metal panels that would otherwise flap around, and to put lips on pieces of sheet that would normally need screws passed through the front face. A bending machine forms angles in sheet metal. Press brake tooling is used in cold-forming metal sheets or strips into desired sections. A CNC brake press is a computer numerically controlled, fully automated brake press with extensive bending capacity and networking function. A sheet metal press brake is used to bend and form sheet metal. Other press brakes are commonly available.
